| Company | SATCO |
|---|---|
| Dimmable Text | Low Voltage |
| Lamp Filament | C-6 |
| Fixture Type | Bi-Pin |
| Status | Active |
| CCT Selectable | No |
| Wattage Selectable | No |
| Finish Family | No Finish |
| Amps | 1.667A |
| Has Camera | No |
| IOT Enabled | No |
| Lens Finish | Clear |
| Lensed | Yes |
| Operating Position | Universal |
| SDS Class | Halogen_Double_Ended_or_Pin_Based_Lamp |
| Product Technology | Halogen |
| CCT (Kelvin Temp) | 2900K |
|---|---|
| Dimmable | Yes-Dimmable |
| Hours Rated | 2000 |
| Beam Angle (degree) | 360 |
| Color Temp | Warm White |
| CRI | 100 |
| Dimming Type | Low Voltage, Phase cut |
| Lumens | 300L |
| Volts | 12V |
| Watts | 20W |
| Lamp Base | Bi Pin GY6.35 |
|---|---|
| Finish | Clear |
| Housing Color | None |
| ANSI Base | GY6.35 |
| Lamp Type | T3 |
| MOD Lamps | 0.38 |
| MOL | 1.25 |
| CA Prop 65 | Lead |
|---|---|
| Location Rating | Damp |
| ROHS Compliant | Yes |
| Safety Listing | Not Applicable |
| California Ban | Lawful for sale |
| DLC Approved | No |
| Title 20 | Exempt |
| T24 Compliant | No |
| UPC | 045923041976 |
|---|---|
| Case Cube | 1.7598 |
| Case Height | 12.61 |
| Case Length | 29.16 |
| Case Quantity | 960 |
| Case UPC | 10045923041973 |
| Case Weight | 11.03 |
| Case Width | 8.27 |
| EA Cube | 0.0012 |
| EA Height | 0.87 |
| EA Length | 2.68 |
| EA Quantity | 1 |
| EA Weight | 0.01 |
| EA Width | 0.87 |
| Inner Cube | 0.0723 |
| Inner Height | 5.79 |
| Inner Length | 5.59 |
| Inner Quantity | 48 |
| Inner UPC | 20045923041970 |
| Inner Weight | 0.53 |
| Inner Width | 3.86 |
| Pack Type | Box |
| Web Length | 1.25 |
| Web Width | 0.38 |
