S8535 9WPLV/LED/827/BP/2P

S8535

9WPLV/LED/827/BP/2P

9 Watt LED PL 2-Pin; 2700K; 900 Lumens; G24d base; 50000 Average rated hours; 120 Deg. Beam Angle; Vertical; Type B; Ballast Bypass


Lights

S8535

9WPLV/LED/827/BP/2P

9 Watt LED PL 2-Pin; 2700K; 900 Lumens; G24d base; 50000 Average rated hours; 120 Deg. Beam Angle; Vertical; Type B; Ballast Bypass

Specifications

General
StatusActive
Watts9W
Fluorescent Equivalent18W/26W
Volts120V-277V
Ballast TypeType B
ShapePL
BaseG24d (2-Pin)
ANSI BaseG24d
FinishFrost
CCT (Kelvin)2700K
TemperatureWarm White
CRI82
Lumens900L
Beam Spread120
DimmableNon-Dimmable
Hours Rated50000
Product CategoryPL
Lamp TypePL
Operating PositionBase Up or Down
TechnologyLED
Electrical
Watts9W
Fluorescent Equivalent18W/26W
Volts120V-277V
Ballasting RequirementsBallast Bypass- Direct wire only 100V-277V
Ballast TypeType B
Operating Frequency50/60Hz
CCT (Kelvin)2700K
TemperatureWarm White
CRI82
Lumens900L
Beam Spread120
DimmableNon-Dimmable
Hours Rated50000
Operating PositionBase Up or Down
Operating Temperature-20C (-4F) to +45C (+113F)
Physical
MOL4.69
MOD1.91
ShapePL
BaseG24d (2-Pin)
ANSI BaseG24d
FinishFrost
Additional Information
Installation Notes2-pin LED lamps work in both 2-pin (magnetic) and 4-pin (electronic) sockets.
Rated For Enclosed FixtureYes
Warranty5 Year Limited - 10 hr per day
Compliance
Safety ListingcULus - Classified; cULus - Certified
Location RatingDamp
Energy StarNo
DLC ApprovedNo
CA T20 / T24 RationaleExempt - Base Not Regulated
RoHS CompliantYes
SDS SheetLED Lamp
Packaging
Each UPC045923085352
Each Quantity1
Each Length (in.)1.93
Each Width (in.)1.93
Each Height (in.)4.84
Each Weight (lb.)0.31
Each Cube (CuFt.)0.0104
Pack TypeBox
Inner UPC20045923085356
Inner Quantity10
Inner Length (in.)10.00
Inner Width (in.)4.17
Inner Height (in.)5.12
Inner Weight (lb.)0.00
Inner Cube (CuFt.)0.1236
Case UPC10045923085359
Case Quantity50
Case Length (in.)11.00
Case Width (in.)10.60
Case Height (in.)10.60
Case Weight (lb.)15.67
Case Cube (CuFt.)0.7153
