| Company | SATCO |
|---|---|
| Lamp Ballast Type AB | Type B |
| Ballasting Requirements | Ballast Bypass- Direct wire only 100V-277V |
| CA Regulations | Exempt - Base Not Regulated |
| Lamp Filament | LED |
| Fixture Type | PL |
| Status | Active |
| Style | Transitional |
| CCT Selectable | False |
| Wattage Selectable | False |
| Finish Family | White |
| Amps | 0.075-0.032A |
| Has Camera | False |
| IOT Enabled | False |
| Lens Finish | Frost |
| Lensed | True |
| Operating Position | Base Up or Down |
| Power Factor | 0.99 |
| SDS Class | LED_Lamp |
| Product Technology | LED |
| Fluor Equiv | 18W/26W |
| Incandescent Equivalent | 40W |
| CCT (Kelvin Temp) | 5000K |
|---|---|
| Dimmable | Non-Dimmable |
| Hours Rated | 50000 |
| Beam Angle (degree) | 120 |
| Color Temp | Natural Light |
| CRI | 80+ |
| Operating Frequency | 50/60Hz |
| Operating Temp | -20C (-4F) to +45C (+113F) |
| Lumens | 1000L |
| Volts | 120V-277V |
| Watts | 9W |
| Lamp Base | G24d (2-Pin) |
|---|---|
| Finish | Frost |
| Housing Color | White |
| ANSI Base | G24d |
| Lamp Type | PL |
| MOD Lamps | 1.91 |
| MOL | 4.69 |
| Warranty | 5-Years |
|---|---|
| Installation Notes | 2-pin LED lamps work in both 2-pin (magnetic) and 4-pin (electronic) sockets. |
| Rated For Enclosed Fixture | True |
| CA Status | Lawful for sale in California |
|---|---|
| CO Status | Lawful for sale |
| FCC Compliant | True |
| HI Status | Lawful for sale |
| Location Rating | Damp |
| NV Status | Lawful for sale |
| ROHS Compliant | Yes |
| Safety Listing | cULus - Certified, cULus - Classified |
| CA Compliance Text | Lawful for sale |
| VT Status | Lawful for sale |
| WA Status | Lawful for sale |
| DLC Approved | False |
| Title 20 | Exempt |
| T24 Compliant | False |
| UPC | 045923085390 |
|---|---|
| Case Cube | 0.7153 |
| Case Height | 11.0 |
| Case Length | 10.6 |
| Case Quantity | 50 |
| Case UPC | 10045923085397 |
| Case Weight | 15.67 |
| Case Width | 10.6 |
| EA Cube | 0.0104 |
| EA Height | 4.84 |
| EA Length | 1.93 |
| EA Quantity | 1 |
| EA Weight | 0.31 |
| EA Width | 1.93 |
| Inner Cube | 0.1236 |
| Inner Height | 10.0 |
| Inner Length | 4.17 |
| Inner Quantity | 10 |
| Inner UPC | 20045923085394 |
| Inner Weight | 0.0 |
| Inner Width | 5.12 |
| Pack Type | Box |
| Web Length | 4.69 |
| Web Width | 1.91 |
