| Company | SATCO |
|---|---|
| Lamp Filament | LED |
| Material | Silicon |
| Fixture Type | Miniature |
| Status | Discontinued |
| Most Current Generation | S12124 |
| CCT Selectable | False |
| Wattage Selectable | False |
| Finish Family | No Finish |
| Amps | 0.250A |
| Has Camera | False |
| IOT Enabled | False |
| Lens Finish | Clear |
| Lensed | True |
| Operating Position | Universal |
| Power Factor | 0.92 |
| SDS Class | LED_Lamp |
| Product Technology | LED |
| Incandescent Equivalent | 25W |
| CCT (Kelvin Temp) | 3000K |
|---|---|
| Dimmable | Yes-Dimmable |
| Hours Rated | 25000 |
| Beam Angle (degree) | 360 |
| Color Temp | Warm White |
| CRI | 80+ |
| Dimming Type | Reverse Phase or Phase Selectable |
| Operating Temp | -20C (-4F) to +45C (+113F) |
| Lumens | 300L |
| Volts | 12V |
| Watts | 3W |
| Lamp Base | Bi Pin G6.35 |
|---|---|
| Finish | Clear |
| ANSI Base | G6.35 |
| Lamp Type | T4 |
| MOD Lamps | 0.5 |
| MOL | 1.63 |
| Warranty | 5-Years |
|---|---|
| Installation Notes | Not for use in vapor tight fixtures. |
| Rated For Enclosed Fixture | True |
| CA Regulations | Exempt - Base Not Regulated |
|---|---|
| CA Status | Lawful for sale in California |
| CO Status | Lawful for sale |
| FCC Compliant | True |
| HI Status | Lawful for sale |
| Location Rating | Damp |
| NV Status | Lawful for sale |
| ROHS Compliant | Yes |
| Safety Listing | cETLus |
| CA Compliance Text | Lawful for sale |
| VT Status | Lawful for sale |
| WA Status | Lawful for sale |
| DLC Approved | False |
| Title 20 | Exempt |
| T24 Compliant | False |
| UPC | 045923086014 |
|---|---|
| Case Cube | 1.0318 |
| Case Height | 18.38 |
| Case Length | 7.25 |
| Case Quantity | 48 |
| Case UPC | 10045923086011 |
| Case Weight | 5.77 |
| Case Width | 13.38 |
| EA Cube | 0.0129 |
| EA Height | 6.13 |
| EA Length | 0.88 |
| EA Quantity | 1 |
| EA Weight | 0.05 |
| EA Width | 4.13 |
| Inner Cube | 0.21 |
| Inner Height | 8.75 |
| Inner Length | 6.38 |
| Inner Quantity | 12 |
| Inner UPC | 20045923086018 |
| Inner Weight | 1.12 |
| Inner Width | 6.5 |
| Pack Type | Carded |
| Web Length | 1.63 |
| Web Width | 0.5 |
