» S8695

Substitute S28695
S8695 12T5/LED/24-850/BP/HO/120-277V

S8695

12T5/LED/24-850/BP/HO/120-277V

12 Watt T5 LED; Miniature bi-pin base; 5000K; 50000 Average rated hours; 1500 Lumens; 120-277 Volt; Type B; Ballast Bypass; Single Ended Wiring

Lights

S8695

12T5/LED/24-850/BP/HO/120-277V

12 Watt T5 LED; Miniature bi-pin base; 5000K; 50000 Average rated hours; 1500 Lumens; 120-277 Volt; Type B; Ballast Bypass; Single Ended Wiring

Specifications

General
StatusDiscontinued
Watts12W
Volts120V-277V
Ballast TypeType B
ShapeT5
BaseMiniature Bi Pin
ANSI BaseG5
Nominal Length24
FinishFrost
CCT (Kelvin)5000K
TemperatureNatural Light
CRI83
Lumens1500L
Beam Spread240
DimmableNon-Dimmable
Hours Rated50000
Lamp TypeLinear
TechnologyLED
Electrical
Watts12W
Volts120V-277V
Ballasting RequirementsBallast Bypass
Ballast TypeType B
Operating Frequency50/60 Hz
CCT (Kelvin)5000K
TemperatureNatural Light
CRI83
Lumens1500L
Beam Spread240
DimmableNon-Dimmable
Hours Rated50000
Physical
MOL24
MOD0.88
Nominal Length24
ShapeT5
BaseMiniature Bi Pin
ANSI BaseG5
FinishFrost
Lens FinishFrost
Housing ColorSilver
Additional Information
Shatter-Proof TypeYes
Warranty5 Year Limited - T5 LED Bulbs - Ballast Bypass
Compliance
Safety ListingcULus - Classified; cULus - Certified; ETLus - SANITATION RECOGNIZED COMPONENT
Location RatingDamp
Energy StarNo
CA T20 / T24 RationaleExempt - Base Not Regulated
California StatusLawful for sale in California
Title 20 / 24 StatusLawful for sale
RoHS CompliantYes
FCC CompliantYes
NSF ApprovedYes
SDS SheetLED Lamp
Packaging
Each UPC045923086953
Each Quantity1
Each Length (in.)22.20
Each Width (in.)0.80
Each Height (in.)0.80
Each Weight (lb.)0.20
Each Cube (CuFt.)0.0082
Pack TypeSleeve
Inner Quantity0
Inner Length (in.)0.00
Inner Width (in.)0.00
Inner Height (in.)0.00
Inner Weight (lb.)0.00
Inner Cube (CuFt.)0.0000
Case UPC10045923086950
Case Quantity25
Case Length (in.)24.50
Case Width (in.)5.20
Case Height (in.)5.20
Case Weight (lb.)8.50
Case Cube (CuFt.)0.3834
