» S9317

S9317 3/9/12A19/3WAY LED/3000K/120V

S9317

3/9/12A19/3WAY LED/3000K/120V

3 Watt/9 Watt/12 Watt; A19 LED; 3-way; Frosted; 3000K; Medium base; 220 deg. Beam Angle; 120 Volt


Lights

S9317

3/9/12A19/3WAY LED/3000K/120V

3 Watt/9 Watt/12 Watt; A19 LED; 3-way; Frosted; 3000K; Medium base; 220 deg. Beam Angle; 120 Volt

Specifications

General
StatusActive
Watts3W/9W/12W
Incandescent Equivalent30W/70W/100W
Volts120V
ShapeA19
BaseMedium
ANSI BaseE26
FinishFrost
CCT (Kelvin)3000K
TemperatureWarm White
CRI80
Lumens280L/950L/1200L
Beam Spread220
DimmableNon-Dimmable
Hours Rated25000
Product CategoryType A
Lamp TypeType A
TechnologyLED
Electrical
Watts3W/9W/12W
Incandescent Equivalent30W/70W/100W
Volts120V
Operating Frequency60Hz
CCT (Kelvin)3000K
TemperatureWarm White
CRI80
Lumens280L/950L/1200L
Beam Spread220
Power Factor0.95
Hours Rated25000
Operating Temperature-25C (-13F) to +45C (+113F)
Physical
MOL4.646
MOD2.362
ShapeA19
BaseMedium
ANSI BaseE26
FinishFrost
Housing ColorWhite
Weight (lb.)0.12
Additional Information
Additional InfoThree way lamp
Rated For Enclosed FixtureYes
Three WayYes
Warranty5 Year Limited - 10 hr per day
Compliance
Safety ListingcULus - Certified; cULus - Listed
Location RatingDamp
Energy StarYes
ES Unique IDESID-2290083
CA T20 / T24 RationaleNon-Compliant - <82 CRI
California StatusNon-Compliant
Title 20 / 24 StatusNon-Compliant
California Compliant SubstituteS8571
RoHS CompliantYes
FCC CompliantYes
SDS SheetLED Lamp
Packaging
Each UPC045923093173
Each Quantity1
Each Length (in.)2.44
Each Width (in.)2.44
Each Height (in.)5.12
Each Weight (lb.)0.20
Each Cube (CuFt.)0.0176
Pack TypeBox
Inner UPC20045923093177
Inner Quantity6
Inner Length (in.)7.80
Inner Width (in.)5.20
Inner Height (in.)5.43
Inner Weight (lb.)1.32
Inner Cube (CuFt.)0.1275
Case UPC10045923093170
Case Quantity24
Case Length (in.)11.22
Case Width (in.)8.46
Case Height (in.)11.93
Case Weight (lb.)5.84
Case Cube (CuFt.)0.6553
