| Company | SATCO |
|---|---|
| Lamp Ballast Type AB | Type B |
| Ballasting Requirements | Ballast Bypass |
| Lamp Filament | LED |
| Fixture Type | Corncob |
| Status | Discontinued |
| Most Current Generation | S39752 |
| Working Voltage | AC 90-305V |
| CCT Selectable | False |
| Wattage Selectable | False |
| Finish Family | No Finish |
| Additional Info | Width 360 deg 3.8 in.; Width 270 deg 8.2 in.; Width 180 deg 9.3 in. |
| Amps | 0.600-0.217A |
| Has Camera | False |
| IOT Enabled | False |
| Lens Finish | Clear |
| Lensed | True |
| Minimum Compartment Size | Length: 8.27 in. Width: 9.25 in. Depth: 9.25 in. |
| Operating Position | Universal |
| Power Factor | >.9 |
| SDS Class | LED_Lamp |
| Product Technology | LED |
| Fluor Equiv | 85W |
| Incandescent Equivalent | 500W |
| CCT (Kelvin Temp) | 5000K |
|---|---|
| Dimmable | Non-Dimmable |
| Hours Rated | 50000 |
| Beam Angle (degree) | 360 |
| Color Temp | Natural Light |
| CRI | 80+ |
| Operating Frequency | 50-60Hz |
| Operating Temp | -20C (-4F) to +65C (+149F) |
| HID Equivalent | 250W |
| Lumens | 7800L |
| Volts | 120V-277V |
| Watts | 60W |
| Lamp Base | Mogul Extended |
|---|---|
| Finish | Clear |
| Housing Color | White |
| ANSI Base | EX39 |
| Lamp Type | Corncob |
| MOD Lamps | 3.81 |
| MOL | 8.56 |
| Warranty | 5-Years |
|---|---|
| Installation Notes | Not for use in vapor tight fixtures. Arms fully open diameter is 9.31 inches |
| Rated For Enclosed Fixture | True |
| CA Regulations | Exempt - Base Not Regulated |
|---|---|
| CA Status | Lawful for sale in California |
| CO Status | Lawful for sale |
| FCC Compliant | True |
| HI Status | Lawful for sale |
| IP Rating | IP65 |
| Location Rating | Damp |
| NV Status | Lawful for sale |
| ROHS Compliant | Yes |
| Safety Listing | cULus - Certified, cULus - Classified |
| CA Compliance Text | Lawful for sale |
| VT Status | Lawful for sale |
| WA Status | Lawful for sale |
| DLC Approved | False |
| Title 20 | Exempt |
| T24 Compliant | False |
| UPC | 045923097522 |
|---|---|
| Case Cube | 2.0906 |
| Case Height | 10.43 |
| Case Length | 21.46 |
| Case Quantity | 12 |
| Case UPC | 10045923097529 |
| Case Weight | 34.45 |
| Case Width | 16.14 |
| EA Cube | 0.2055 |
| EA Height | 10.2 |
| EA Length | 5.9 |
| EA Quantity | 1 |
| EA Weight | 2.66 |
| EA Width | 5.9 |
| Inner Cube | 0.8596 |
| Inner Height | 10.24 |
| Inner Length | 15.35 |
| Inner Quantity | 6 |
| Inner UPC | 20045923097526 |
| Inner Weight | 16.38 |
| Inner Width | 9.45 |
| Pack Type | Box |
| Web Length | 8.56 |
| Web Width | 3.81 |
