SKU S28946 - Image 1
S28946

100W/LED/HID/TEMP/5K/120V

Discontinued - Suggested Replacement: S38946
  • 100 Watt LED Hi-lumen temporary hi-bay caged lamp
  • 5000K
  • Integrated cord / plug and hook
  • 120 Volt
location_rating^damp^1
hours_rated^50k^2
volts^120v^2
fcc_compliant^true^3
rohs_compliant^y^3
S28946 SpecificationsS28946 InstructionsSA2283 Hi-Pro Caged Work Light V2 5 18
Tools
Lighting Layout Analysis For S28946
Create your own analysis for this Part Number
Custom Lighting Layout Analysis
Request a lighting layout
Description
Description
100 Watt LED Hi-lumen temporary hi-bay caged lamp; 5000K; Integrated cord / plug and hook; 120 Volt
Products Specs
General
CompanySATCO
Bulb IncludedIntegrated
Fixture TypeCorncob
IncludesOutlet for connecting multiple lamps
Product NotesInternal, resettable 5A fuse installed.In case of an overload, reset the fuse.If only the first lamp turns on, disconnect the extras and wait 10 seconds cool-down time.
StatusDiscontinued
Most Current GenerationS38946
CCT SelectableFalse
Wattage SelectableFalse
Finish FamilyWhite
Additional InfoRemote control operation; Retractable handle; 3 ft. cord with plug
Amps0.833A
Has CameraFalse
IOT EnabledFalse
Lens FinishWhite
LensedTrue
NEMA Plug5-15 Three Prong
Power Factor>0.9
SDS ClassLED_Lamp
Product TechnologyLED
Incandescent Equivalent500W
Electrical
CCT (Kelvin Temp)5000K
DimmableNon-Dimmable
Hours Rated50000
Beam Angle (degree)360
Color TempNatural Light
CRI85+
Operating Temp-30C (-22F) to +60C (+140F)
Lumens10000L
Volts120v
Watts100W
Physical
Lamp BasePlug 3-Prong
FinishWHITE
Housing ColorYellow
ANSI BaseNEMA 5-15
Lamp TypeCorncob
Additional Info
Warranty5-Years
Documents
Compliance
CA RegulationsExempt - Base Not Regulated
CA Prop 65Lead
CA StatusLawful for sale in California
CO StatusLawful for sale
FCC CompliantTrue
HI StatusLawful for sale
IP RatingIP64
Location RatingDamp
NV StatusLawful for sale
ROHS CompliantYes
Safety ListingcULus - Certified
CA Compliance TextLawful for sale
UL ApplicationLight-emitting-diode Luminaires, Portable
VT StatusLawful for sale
WA StatusLawful for sale
DLC ApprovedFalse
Energy Star CertifiedNo
Title 20Exempt
T24 CompliantFalse
Packaging
UPC045923289460
Case Cube2.6271
Case Height17.32
Case Length17.52
Case Quantity4
Case UPC10045923289467
Case Weight24.0
Case Width14.96
EA Cube0.5762
EA Height8.19
EA Length14.37
EA Quantity1
EA Weight5.94
EA Width8.46
Inner Cube0.0
Inner Height0.0
Inner Length0.0
Inner Quantity0
Inner Weight0.0
Inner Width0.0
Pack TypeBox
Web Length12.0
Web Width6.25
