| Company | SATCO |
|---|---|
| Fixture Type | Circline |
| Hg Content | 7.5 |
| Status | Active |
| CCT Selectable | False |
| Wattage Selectable | False |
| Finish Family | White |
| Has Camera | False |
| IOT Enabled | False |
| Lens Finish | Gloss White |
| Lensed | True |
| Mean Lumens | 1640 |
| Nominal Length | 12.0 |
| Operating Position | Universal |
| SDS Class | Linear_Fluorescent_Lamp |
| Product Technology | Fluorescent |
| CCT (Kelvin Temp) | 4100K |
|---|---|
| Dimmable | Non-Dimmable |
| Hours Rated | 12000 |
| Beam Angle (degree) | 360 |
| Color Temp | Cool White |
| CRI | 60+ |
| Operating Temp | Ballast Dependent |
| Lumens | 1930L |
| Watts | 32W |
| Lamp Base | G10q (4-Pin) |
|---|---|
| Finish | Gloss White |
| Housing Color | None |
| ANSI Base | G10q |
| Lamp Type | T9 |
| MOD Lamps | 1.13 |
| MOL | 12.0 |
| Warranty | 3-Years |
|---|---|
| Installation Notes | Outer Diameter is 12 inches |
| CA Regulations | Non-Compliant - Mercury Content |
|---|---|
| CA Prop 65 | Lead |
| CA Status | Non-Compliant |
| CO Status | Non-Compliant |
| HI Status | Non-Compliant Effective 1-1-2026 |
| NV Status | Lawful for sale |
| OR Status | Non-Compliant |
| RI Status | Non-Compliant |
| ROHS Compliant | Yes |
| CA Compliance Text | Non-Compliant |
| VT Status | Non-Compliant |
| WA Status | Lawful for sale |
| DLC Approved | False |
| Title 20 | No |
| T24 Compliant | False |
| UPC | 045923065033 |
|---|---|
| Case Cube | 1.5913 |
| Case Height | 12.6 |
| Case Length | 17.32 |
| Case Quantity | 12 |
| Case UPC | 10045923065030 |
| Case Weight | 9.39 |
| Case Width | 12.6 |
| EA Cube | 0.1265 |
| EA Height | 12.13 |
| EA Length | 1.5 |
| EA Quantity | 1 |
| EA Weight | 0.68 |
| EA Width | 12.01 |
| Inner Cube | 0.0 |
| Inner Height | 0.0 |
| Inner Length | 0.0 |
| Inner Quantity | 0 |
| Inner Weight | 0.0 |
| Inner Width | 0.0 |
| Pack Type | Hang Box |
| Web Length | 12.0 |
| Web Width | 1.13 |
