» S11924

Substitute S21924
S11924 14T8/LED/48-865/BP 120-277V

S11924

14T8/LED/48-865/BP 120-277V

14 Watt T8 LED; Medium bi-pin base; 6500K; 50000 Average rated hours; 1800 Lumens; Type B; Ballast Bypass; Double Ended Wiring

Lights

S11924

14T8/LED/48-865/BP 120-277V

14 Watt T8 LED; Medium bi-pin base; 6500K; 50000 Average rated hours; 1800 Lumens; Type B; Ballast Bypass; Double Ended Wiring

Specifications

General
StatusDiscontinued
SubstituteS21924
Watts14W
Fluorescent Equivalent25W-32W
Volts120V-277V
Ballast TypeType B
ShapeT8
BaseMedium Bi Pin
ANSI BaseG13
Nominal Length48
FinishFrost
CCT (Kelvin)6500
TemperatureDaylight
CRI82
Lumens1800L
Beam Spread210
DimmableNon-Dimmable
Hours Rated50000
Lamp TypeLinear
TechnologyLED
Electrical
Watts14W
Fluorescent Equivalent25W-32W
Volts120V-277V
Ballasting RequirementsBallast Bypass; Direct wire 120-277V line voltage; No ballast or external driver required
Ballast TypeType B
Operating Frequency50/60 Hz
CCT (Kelvin)6500
TemperatureDaylight
CRI82
Lumens1800L
Beam Spread210
DimmableNon-Dimmable
Power Factor0.9
Hours Rated50000
Operating Temperature-20C (-4F) to a maximum of +45C (+113F)
Physical
MOL48
MOD1
Nominal Length48
ShapeT8
BaseMedium Bi Pin
ANSI BaseG13
FinishFrost
Lens FinishFrost
Additional Information
Additional InfoAll glass tube; Built-in shock resistant circuit
Tube Guard UseApproved for use with tube guards
Warranty5 Year Limited - T8 LED Bulbs - Ballast Bypass
Compliance
Safety ListingcULus Classified
Location RatingDamp
Energy StarNo
California StatusLawful for sale
RoHS CompliantYes
FCC CompliantYes
Packaging
Each UPC045923119248
Each Quantity1
Each Length (in.)48.00
Each Width (in.)1.00
Each Height (in.)1.00
Each Weight (lb.)0.50
Each Cube (CuFt.)0.0278
Pack TypeSleeve
Inner Quantity0
Inner Length (in.)0.00
Inner Width (in.)0.00
Inner Height (in.)0.00
Inner Weight (lb.)0.00
Inner Cube (CuFt.)0.0000
Case UPC10045923119245
Case Quantity25
Case Length (in.)49.00
Case Width (in.)5.90
Case Height (in.)5.90
Case Weight (lb.)14.40
Case Cube (CuFt.)0.9871
×
×

Ballast Compatibility

Name Type View
LED Linear S11924 Ballasts View
×

Precautions

No precautions available at this time.

×
