| Company | SATCO |
|---|---|
| Lamp Ballast Type AB | Type B |
| Ballasting Requirements | Ballast Bypass |
| Lamp Filament | LED |
| Material | Glass / Metal |
| Fixture Type | LED HID |
| Status | Discontinued |
| Style | Utility |
| Most Current Generation | S13190 |
| CCT Selectable | False |
| Wattage Selectable | False |
| Finish Family | White |
| Additional Info | HI-PRO Filament 120-277V |
| Amps | 0.350-0.152A |
| Has Camera | False |
| IOT Enabled | False |
| Lens Finish | White |
| Lens Material | Glass |
| Operating Position | Universal |
| Power Factor | 0.9 |
| SDS Class | LED_Lamp |
| Indoor Outdoor | Indoor, Outdoor |
| Product Technology | LED |
| Fluor Equiv | 85W |
| Incandescent Equivalent | 300W |
| CCT (Kelvin Temp) | 5000K |
|---|---|
| Dimmable | Non-Dimmable |
| Hours Rated | 25000 |
| Beam Angle (degree) | 360 |
| Color Temp | Natural Light |
| CRI | 80+ |
| Operating Frequency | 60Hz |
| Operating Temp | -30C (-22F) to +65C (+149F) |
| HID Equivalent | 175W |
| Lumens | 6000L |
| Volts | 120V-277V |
| Watts | 42W |
| Lamp Base | Mogul Extended |
|---|---|
| Finish | WHITE |
| Housing Color | White |
| ANSI Base | EX39 |
| Lamp Type | ED28 |
| MOD Lamps | 3.54 |
| MOL | 8.54 |
| Warranty | 5-Years |
|---|---|
| Installation Notes | Not for use in vapor tight fixtures. |
| Rated For Enclosed Fixture | True |
| CA Regulations | Exempt - Base Not Regulated |
|---|---|
| CA Status | Lawful for sale in California |
| CO Status | Lawful for sale |
| FCC Compliant | True |
| HI Status | Lawful for sale |
| IP Rating | IP65 |
| Location Rating | Wet |
| NV Status | Lawful for sale |
| ROHS Compliant | Yes |
| Safety Listing | cULus - Certified, cULus - Classified, cULus - Listed |
| CA Compliance Text | Lawful for sale |
| VT Status | Lawful for sale |
| WA Status | Lawful for sale |
| DLC Approved | False |
| Title 20 | Exempt |
| T24 Compliant | False |
| UPC | 045923131363 |
|---|---|
| Case Cube | 2.4447 |
| Case Height | 11.42 |
| Case Length | 21.85 |
| Case Quantity | 12 |
| Case UPC | 10045923131360 |
| Case Weight | 12.13 |
| Case Width | 16.93 |
| EA Cube | 0.1169 |
| EA Height | 9.84 |
| EA Length | 4.53 |
| EA Quantity | 1 |
| EA Weight | 0.74 |
| EA Width | 4.53 |
| Inner Cube | 0.0 |
| Inner Height | 0.0 |
| Inner Length | 0.0 |
| Inner Quantity | 0 |
| Inner Weight | 0.0 |
| Inner Width | 0.0 |
| Pack Type | Color Box |
| Web Length | 8.54 |
| Web Width | 3.54 |
