| Company | SATCO |
|---|---|
| Lamp Ballast Type AB | Type B |
| Ballasting Requirements | Ballast Bypass |
| Lamp Filament | LED |
| Material | Plastic |
| Fixture Type | Type A |
| Status | Obsolete |
| Style | Contemporary |
| CCT Selectable | No |
| Wattage Selectable | No |
| Finish Family | White |
| Amps | 0.350-0.126A |
| Has Camera | No |
| IOT Enabled | No |
| Lens Finish | Frost |
| Lens Material | Plastic (PS) |
| Lensed | Yes |
| Minimum Compartment Size | Diameter: 6 in. Height: 8.5 in. |
| Operating Position | Universal |
| Power Factor | >0.9 |
| SDS Class | LED_Lamp |
| Product Technology | LED |
| Incandescent Equivalent | 300W |
| CCT (Kelvin Temp) | 2700K |
|---|---|
| Dimmable | Non-Dimmable |
| Hours Rated | 50000 |
| Beam Angle (degree) | 280 |
| Color Temp | Warm White |
| CRI | 80+ |
| Operating Frequency | 50/60Hz |
| Operating Temp | -13F to +113F (-25C to +45C) |
| HID Equivalent | 150W |
| Lumens | 4480L |
| Volts | 120V-277V |
| Watts | 35W |
| Lamp Base | Mogul Extended |
|---|---|
| Finish | Frost |
| Housing Color | White |
| ANSI Base | EX39 |
| Lamp Type | A25 |
| MOD Lamps | 3.75 |
| MOL | 7.25 |
| Warranty | 5-Years |
|---|---|
| Installation Notes | Not for use in vapor tight fixtures. |
| Rated For Enclosed Fixture | Yes |
| FCC Compliant | Yes |
|---|---|
| Location Rating | Damp |
| ROHS Compliant | Yes |
| Safety Listing | cULus - Certified, cULus - Classified, cULus - Listed |
| California Ban | Lawful for sale |
| DLC Approved | No |
| Title 20 | Exempt |
| T24/JA8 Compliant | No |
| UPC | 045923131080 |
|---|---|
| Case Cube | 1.8927 |
| Case Height | 11.0 |
| Case Length | 15.9 |
| Case Quantity | 12 |
| Case UPC | 10045923131087 |
| Case Weight | 24.25 |
| Case Width | 18.7 |
| EA Cube | 0.1251 |
| EA Height | 8.79 |
| EA Length | 4.96 |
| EA Quantity | 1 |
| EA Weight | 1.56 |
| EA Width | 4.96 |
| Pack Type | Box |
| Web Length | 7.25 |
| Web Width | 3.75 |
