S9472

12WLED/DIR/5-6/27K/120V

Discontinued - Suggested Replacement: S11824
  • 12 watt LED Directional Retrofit Downlight - Gimbaled
  • 5"-6"
  • 2700K
  • 120 volts
  • Dimmable
location_rating^wet^2
cri^90+^2
dimmable^dimmable^2
hours_rated^50k^2
volts^120v^2
safety_listing^culus_clas^3
fcc_compliant^true^3
rohs_compliant^y^3
Description
Description
12 watt LED Directional Retrofit Downlight - Gimbaled; 5"-6"; 2700K; 120 volts; Dimmable
Products Specs
General
CompanySATCO
Bulb IncludedIntegrated
Diameter6.75
Fixture TypeDownlight Retrofit
StatusObsolete
StyleContemporary
Most Current GenerationS11824
CCT SelectableFalse
Wattage SelectableFalse
Can Size5-6 in.
Finish FamilyWhite
Amps0.100A
Has CameraFalse
IOT EnabledFalse
SDS ClassLED_Fixture
Indoor OutdoorIndoor
Product TechnologyLED
Incandescent Equivalent65W
Electrical
CCT (Kelvin Temp)2700K
DimmableYes-Dimmable
Hours Rated50000
Beam Angle (degree)90
Color TempWarm White
CRI90+
Dimming TypeForward Phase or Reverse Phase or Phase Selectable
Operating Temp-20C (-4F) to +45C (+113F)
Lumens800L
Volts120v
Watts12W
Physical
Lamp BaseMedium Adapter
FinishWHITE
ANSI BaseE26 Adapter
Lamp TypeIntegrated LED
Fixture ShapeRound
Additional Info
Warranty5-Years
Compliance
CA RegulationsT20 Non-Compliant - LPW <80
CA Prop 65Lead
CA StatusNon-Compliant
FCC CompliantTrue
Location RatingWet
ROHS CompliantYes
Safety ListingcULus - Certified, cULus - Classified
CA Compliance TextNon-Compliant
DLC ApprovedFalse
Energy Star CertifiedNo
Title 20No
T24 CompliantFalse
Packaging
UPC045923094729
Case Cube1.5746
Case Height8.08
Case Length22.14
Case Quantity8
Case UPC10045923094726
Case Weight13.94
Case Width15.21
EA Cube0.1636
EA Height7.29
EA Length7.29
EA Quantity1
EA Weight1.59
EA Width5.32
Inner Cube0.0
Inner Height0.0
Inner Length0.0
Inner Quantity0
Inner Weight0.0
Inner Width0.0
Pack TypeBox
Web Height4.25
Web Width6.75
