S29851 9WPLH/LED/835/DR/4P

S29851

9WPLH/LED/835/DR/4P

9 Watt LED PL 4-Pin; 3500K; 1050 Lumens; G24q base; 50000 Average rated hours; 120 Deg. Beam Angle; Type A; Ballast dependent


Lights

S29851

9WPLH/LED/835/DR/4P

9 Watt LED PL 4-Pin; 3500K; 1050 Lumens; G24q base; 50000 Average rated hours; 120 Deg. Beam Angle; Type A; Ballast dependent

Specifications

General
StatusActive
Watts9W
Fluorescent Equivalent26W/32W/42W
Volts120V-277V
Ballast TypeType A
ShapePL
BaseG24q (4-Pin)
ANSI BaseG24q
FinishFrost
CCT (Kelvin)3500K
TemperatureNeutral White
CRI82
Lumens1050L
Beam Spread120
Hours Rated50000
Product CategoryPL
Lamp TypePL
Operating PositionHorizontal
TechnologyLED
Electrical
Watts9W
Fluorescent Equivalent26W/32W/42W
Volts120V-277V
Ballasting RequirementsBallast required
Ballast TypeType A
Working VoltageBallast dependent
Operating Frequency50/60Hz
CCT (Kelvin)3500K
TemperatureNeutral White
CRI82
Lumens1050L
Beam Spread120
Power Factor0.9
Hours Rated50000
THD20%
Operating PositionHorizontal
Operating Temperature-20C (-4F) to +45C (+113F)
Physical
MOL6.63
MOD1.09
ShapePL
BaseG24q (4-Pin)
ANSI BaseG24q
FinishFrost
Housing ColorWhite
Additional Information
Rated For Enclosed FixtureYes
Warranty5 Year Limited - 10 hr per day
Compliance
Safety ListingcULus
Location RatingDamp
Energy StarNo
DLC ApprovedYes
DLC IDPZGSP7ZP
CA T20 / T24 RationaleExempt - Base Not Regulated
California Prop 65
RoHS CompliantYes
SDS SheetLED Lamp
Packaging
Each UPC045923298516
Each Quantity1
Each Length (in.)1.50
Each Width (in.)1.50
Each Height (in.)6.80
Each Weight (lb.)0.22
Each Cube (CuFt.)0.0089
Pack TypeBox
Inner UPC20045923298510
Inner Quantity10
Inner Length (in.)8.00
Inner Width (in.)3.30
Inner Height (in.)7.09
Inner Weight (lb.)2.06
Inner Cube (CuFt.)0.1083
Case UPC10045923298513
Case Quantity50
Case Length (in.)14.50
Case Width (in.)8.60
Case Height (in.)9.00
Case Weight (lb.)12.00
Case Cube (CuFt.)0.6495
×
×

Ballast Compatibility

Name Type View
PL 4 Pin Electronic LED CFL Replacements Pin Based View
Dimming Ballast LED CFL Replacements Pin Based View
×

Precautions

No precautions available at this time.

×
California Prop 65 Warnings
Material Warning
Lead WARNING: This product can expose you to chemicals including Lead and lead compounds, which are known to the State of California to cause cancer or birth defects or other reproductive harm.
